Features

Specifications

Condition: New

Raw Material Processed: Grass, Rice Husk, Wood Sawdust, Biomass, Straw, Cotton Stalks

Pellet Diameter (mm): 2.5 - 8

Output (kg/h): 350 - 450 Kg/h

Voltage: 380v 50HZ Or As Customers'requirement

Dimension(L*W*H): 1400*700*1600mm

Motor Power (Kw): 30

Power (kW): 30

Warranty: 1 Year

Applicable Industries: Manufacturing Plant, Farms, Retail, Construction WorksÂ

Key Selling Points: Easy To Operate

Weight (KG): 900 KG

Marketing Type: New Product 2020

Machinery Test Report: Provided

Video Outgoing-inspection: Provided

Warranty Of Core Components: 1 Year

Core Components: Bearing, Motor, Pump, Gear, Other, Engine, Pressure Vessel, Gearbox

Application: Make Biomass Pellets

Name: Wood Pelletizing Equipment Biomass Sawdust Pellet Mill Machine

Product Name: Wood Pellet Fuel

Raw Material: Sawdust\straw\rice Husk\wood Waste

Usage: Biomass Industry

Function: Making Sawdust Pellet

Capacity: 400-600kg/h

Color: Customer's Request

Keywords: Flat Die R-type Wood Pellet Machine

Certification: CE ISO9001

Showroom Location: None

Basic Infomation

Certification: CE ISO9001

Payment & Shipping Terms

Packaging Details: Standard export wooden case protective film , or as clients ' requirements

Supply Ability: 1000 Set/Sets per Month

Product Description

This animal feeding pellet machine is also a wood sawdust pellet machine having Four types driven fuel :(1)electricity motor , (2.)diesel engine driven , 3) gasoline , and (4). PTO series , which can be used on the tractor directly .

Full Automatic industrial wood pellet machine for making wood pellet pellet grinder machine

technology.

It has the advantages of low investment, simple operation, easy maintenance and high granulation rate. Users can choose different apertures according to their needs. Different sizes of granules can also be selected according to different materials, and different dies can be made to make granules suitable for different poultry.

What is pellet machine? Granulator/pellet machine is one set pressing the material (sawdust, corn straw, peanut shell, straw, cotton straw, twigs, edible fungus waste and cow dung and other raw materials) into high density combustible quality particles of special mechanical equipment.

What is a flat die pellet machine?

Flat model granulator is a granulator, the main use of vertical pressure will be pressed into particles. Biomass raw materials are fed into the feed room of the flat mould machine, and all the materials fall on the flat mould. The spindle drives the grinding disc to rotate, and the press roller continuously rolls through the material layer to squeeze the material into the die hole, where the material undergoes the process of forming and retaining the mold, and after a certain period of time, the material is extruded in the cylindrical state, and the cutter cuts off the material to form particles, which are sent out by the throwing material disc.

Model	ZLSP-R400B
Motor power	30kw
wood pellet capacity	400-600kg/h
Weight	880/940kg
Dimension	14007001600mm
Function	making wood pellet R-type roller movement

Our is one R-TYPE biomass homemade pellet maker has better performance for hardwood like beech, birch cypress, elm tree, hickory, oak, etc. than D-type. The wood pellet fuel maker can make sawdust pellets with better quality, higher density and smoother surface, and all its parts are better than D-type home pellet maker but also with higher price. It is often a good choice for people who want tomake pellets for sale.

what is the advantage of flat - die particle machine?

1. The gear box is made of high quality grey cast iron with low noise and good shock absorption. 2. Bevel gear drive is adopted, which is more efficient than belt drive and worm gear drive, and can avoid belt slipping and short life of belt in belt drive.

3.The shell is reinforced and the casting thickness is increased, which greatly strengthens the machine strength and eliminates the shell fracture of the feed pellet machine.

4.The die plate and press roller are made of high quality alloy steel with hardness up to 55-60hrc.

5. The most suitable die hole structure for wood chip processing, the core technology obtained through a lot of experiments -- the best die hole compression ratio.

6. Safe electronic control system, fully compliant with CE standard operating system, emergency stop button can quickly shut down the machine in case of emergency.

Introduction and characteristics of pellet feed. (why granular feed?) In the process of production, under the pressure of the machine itself, the starch in the feed can produce a certain degree of maturation, producing a strong flavor, and the feed texture is hard, in line with the biological characteristics of animal food, improve the palatability of the feed, easy to eat. 2. The high temperature generated during particle formation can denaturate trypsin resistance factors in grains and beans, reduce adverse effects on digestion, kill various parasitic worm eggs and other pathogenic microorganisms, and reduce parasitic diseases and diseases of the digestive tract. 3. Convenient feeding, high utilization rate, easy to control feeding amount, saving feed, clean and hygienic. In particular, fish culture, because the pellet feed in the water dissolved slowly, will not be submerged by sediment, can reduce waste.

Spare parts :

Five different types :

TItle	Factory supply wood pellet machine/machine to make wood pellets/wood pellet production line
Model	ZLSP 300B
electricity motor power	3 phase 22kw
Motor rotation speed	1430r/min
Animal feed output	600-800kg/h
Net / Gross weight	437/485kg
Package size	13505601220mm

Title	Factory supply wood pellet machine/machine to make wood pellets/wood pellet production line
model	ZLSP-S -260A
diesel engine power	30PH
animal feed output	400-600kg/h
Net/Gross weight	490/530kg
pakage size	19508501120mm

Title	Factory supply wood pellet machine/machine to make wood pellets/wood pellet production line
Model	ZLSP-300C
Motor rotation speed	1470r/m
Power	22kw
feed output	600-800kg
weight	465kg/510kg
Dimension	13206201220mm

Title	Factory supply wood pellet machine/machine to make wood pellets/wood pellet production line
Model	ZLSP-S120Q
Gasoline power	7.5 HP
feed output	60-100kg/h
Weight	120/140kg
Dimension	900500730mm
Drive by gasoline horsepower

Tiltle	Factory supply wood pellet machine/machine to make wood pellets/wood pellet production line
Model	ZLSP-S-120P
Motor power	≥8PH
Feed pellt output	90-120kg/h
Net/GrossWeight	105/125kg
Dimension	9005401020mm

Parameters:

Electricity type	Model	Motor power	wood pellet capacity	Weight	Dimension
		ZLSP-R 200B	3Phase 7.5kw	80-120kg/h	245kg	9504501070mm
		ZLSP-R 300B	3 Phase 22kw	250-350kg/h	670kg	13507501520mm
		ZLSP-R 400B	3 Phase 30kw	350-450kg/h	940kg	14007001600mm
Electricity type R type	ZLSP-R 420B	3 Phase 37kw	400-600kg/h	1150kg	15008001750mm
Electricity type R type		ZLSP-R 550B	3 Phase 55kw	600-900kg/h	2000kg	23008001900mm

Diesle engine	Model	Engine Horse - Power	Animal pellet capacity	Wood pellet capacity	Weight(kg	Dimension (mm)
		ZLSP-S 120A	8PH	60-100kg/h	------	140/165kg	900500730mm
		ZLSP-S 150A	8PH	90-120kg/h	50-100kg/h	165/190kg	1000500750mm
		ZLSP-S 200A	15PH	200-300kg/h	80-120kg/h	330/420kg	1460750900mm
Diesle engine	ZLSP-S 230A	22PH	300-400kg/h	120-200kg/h	420/450kg	15608501000mm
		ZLSP-S 260A	33PH	400-600kg/h	160-250kg/h	470/510kg	12005001070mm
		ZLSP-S 300A	41PH	600-800kg/h	250-400kg/h	850/890kg	12206001100mm
		ZLSP-S 400A	55PH	800-1000kg/h	350-450kg/h	980/1030kg	23008501300mm

Application:

The Raw materials of

animal poultry dog rabbit food feed pellet making machine :

Wood (sawdust) as the main raw materials, branches, straw, cornstalks, sorghum poles, corn cobs, straw, rice husks, peanut shells,
bamboo chips, peanut skin, sunflower seed shells, oil tea shells, cottonseed hulls, furfural slag, wine Slag, mushroom stick,
bagasse, corn cob, coconut shell, coffee shell etc.

Package:

animal poultry dog rabbit food feed pellet making machine

package of pellet machine

animal poultry dog rabbit food feed pellet making machine

pellet machine workshop

Customer Photos

Part of customer's visit .
